6 KVA - 500 KVA for 3 Phase - 3 Phase
| Sr.No. | Rating | 6 KVA - 500 KVA | ||
|---|---|---|---|---|
| 1. | Input Voltage range | 360 V - 470 V ( Three phase) | ||
| 2. | Input frequency range | 50 Hz | ||
| 3. | Nominal Output Voltage | 415 V internally settable to 380 V or 400 V | ||
| 4. | Type of stabilizer | Suitable for unbalanced loads and wide input voltages | ||
| 5. | Output voltage regulation | ± 1% of nominal output voltage | ||
| 6. | Average Correction rate | 70 V / sec. | ||
| 7. | Servo Motor driver | A.C. synchronous stepper motor | ||
| 8. | Single phasing prevention | By voltage sensing method | ||
| 9. | Fault annunciation panel non latching LED indications ON High / Low Latching LED Indication Cut Off |
|
||
| 10. | Resetting mode | Automatic restart with option for manual restart | 11. | Housing | Rack with pleasing aesthetics and foreign particles |
| 12. | Input / Output terminations | 8 - way termination connector for cable terminations and plates for fixing cable glands. | ||
| 13. | Efficiency | > 97% | ||
| 14. | Metering | Analog meter for Volt, Current, frequency Input & output | ||
| 15. | Electronic under / over voltage Cut off Upper limit Lower limit | 20 ± 4 V above nominal 40 ± 4V below nominal | ||
